3-axle Material trailer 1/16

2-Axle Material Trailer, As in the original and in the model, the 2-axle building material trailer reflects its attractive workmanship and appearance. This makes the trailer an unmistakable companion on real roads and as a model on the course. The torsion-resistant frame made of sheet steel enables a payload of approx. 5,500 g. A new suspension is also included, this can optionally be raised by 8 mm and thus compensates for the coupling level to a raised articulated tractor. However, this can also be installed without a lift, both suspension variants are included in the kit. The built-in shock absorbers and air spring dummies function as on / off spring travel limiters. This enables a higher axle articulation and reproduces a driving image true to the original. A suitable optional accessory set (item code: 907623) refines the trailer with compressed air tanks, spare wheel with bracket and a lashing set.

Technical details:

- Torsion-resistant steel frame in sandwich construction

- Frame made of 3 and 1 mm sheet steel, laser cut and CNC bent

- Bogie made of sheet steel in sandwich construction

- Bearing mounted bogie (adjustable) with sliding pad for easy maneuvering

- Drawbar (one-piece) made of fiber-reinforced plastic with checkered plate application

- The drawbar is held by two tension springs for easier attachment

- Coupling height 75 mm

- CNC milled aluminum side panels with detailed surface engravings

- The side walls are locked by neodymium magnets

- All 5 drop sides are functional

- 5 hinges per side wall

- 4 hinges on the rear drop side

- Real wood floor application

- Chrome rims with ball bearings and wide tires

- Solid underrun protection made of steel (left / right)

- Detailed semi-trailer axles with dummy air springs, optionally with elevation by + 8mm (kit contains both versions with / without elevation)

- Mudguards with splash guards

- Bumper rag set

- CNC machined aluminum rear bumper

- Decor set, detailed building instructions

Dim. Trailer: LxWxH: 700 x 195 x 225 mm, Weight: 4,100 g

Dim. Structure: LxWxH: 550 x 195 x 130 mm Height of side wall 75 mm, loading height 110mm

item code: 907624

Attention! Not suitable for children under 14 years.

3-AXLE STANCHION TRAILER III, NEW SUSP. The new 3-axle stanchion trailer from CARSON for transporting logs or similar long loads is a perfect addition to the TAMIYA tractors. The basis for the trailer is a newly developed torsion-resistant frame (sandwich construction) made of 3 and 1 mm laser-cut sheet steel. A new suspension is also included, this can optionally be raised by 8 mm and thus balances the level of the saddle to a higher tractor. However, this can also be installed without a lift, both suspension variants are included in the kit. The built-in shock absorbers and air spring dummies function as on / off spring travel limiters. This enables a higher axle articulation and reproduces a driving image true to the original. Depending on the load and requirements, the six aluminum stanchions can be steplessly positioned on the chassis or removed. These are loosened or fixed using the two countersunk grub screws. A massive steel front wall secures the load to the front of the tractor. Two work lights can be optionally mounted on the front wall and also on the rear frame, the fixings are already provided. A stable underrun protection and a spare wheel holder made of steel complete the detailing of the model.

Technical details:

- Torsion-resistant steel frame in sandwich construction

- Frame made of 3 and 1 mm sheet steel, laser cut and CNC bent

- Solid steel front wall

- Stakes (one-piece) milled from solid aluminum

- The stanchion bracket can be loosened using two grub screws and repositioned or removed as required.

- Detailed semi-trailer axles with dummy air springs, optionally with elevation by + 8mm - Solid underrun protection made of steel (left / right)

- One-arm spare wheel holder made of steel with spare wheel

- Chrome rims with ball bearings and wide off-road tires

- 7-chamber taillights and license plate holder included

- Decor set, detailed building instructions

Dimensions: LxWxH: 980 x 190 x 310 mm, weight: 5,100 g

Attention! Not suitable for children under 14 years.

item code: 907629

2-axle dolly rigid for Gigaliners, in Tamiya scale, with fifth wheel for mounting Tamiya and Carson semi-trailers.

- steel frame (laser cut and welded)

- 7 chamber taillights

- 8-way ball-bearing wheels

- Air spring dummies

- Saddle plate made of plastic

- Tiller made of aluminum, adjustable in length and height

Technical specifications:
Length: 365mm
Width: approx. 195mm
Height: about 85mm

item code : 907210

Warning! Not suitable for children under 14 years.
