Lighting set for 2-axle trailer
Lighting set, suitable for 2-axle trailer item code: 251003, to transfer the lighting functions from the tractor to the trailer.
Set consists of:
1x spiral cable with plug
2x lighting boards for the rear lights (red shining)
1x socket with cable ( for the connection of a second trailer )
2x heat shrink tubing
Building instruction
item code: 251004
Attention. Not suitable for children under 14 years.
Lighting set for the Büssing 8000 S13
Lighting set for the Büssing 8000 S13
consisting of:
1x electronic unit with the following features:
Toggle switch for switching the power supply on and off
battery connection cable with T-plug
terminal strips for the connection of the different lighting boards
Servo cable for the connection to the receiver (switching functions)
Plug connection for connecting the socket at the rear (trailer)
Switching functions: parking light, low beam, high beam, fog light, rear lights
Brake light function via the output from the speed controller (S10 from Servonaut)
Transmission of the rear and brake light function to the trailer (socket)
2x lighting boards for the main headlight with reflector (warm glowing)
2x lighting boards for the fog lights (yellow shining)
2x lighting boards for the rear lights (red shining)
1x cable set with plug connection for the transmission of the light functions to the trailer (socket with holder)
item code: 251002
Attention. Not suitable for children under 14 years.
7,4V/1300mAh 20C LiPO battery
7,4V/1300mAh 20C LiPO battery, T-Plug connector, suitable for the Büssing S8000 S13 ( item code: 251000 ) in connection with the lighting - set ( item code: 251002 ) or loader caterpillar LR 634 ( item code: 907111 ), content: 1 LIPO battery
item code: 608107
Attention. Not suitable for children under 14 years.
Servo CS-6
Servo CS-6, power 6kg, low design, splash-proof, metal gear, JR - servo plug, cable approx. 250mm length, suitable for the Büssing 8000 S13 ( item code: 251000 ), content: 1 servo, 1 servo horn set
item Code: 502047
Attention. Not suitable for children under 14 years.
Achtung! Nicht für Kinder unter 14 Jahren geeignet.
2-axle trailer
2-axle trailer in scale 1/16
suitable for the Büssing 8000 S13 ( item no. 251000 )
( the expected delivery date is in November )
The original from 1946 had a permissible total weight of 12 tons and had twin tires. Until the beginning of the 50's it was even allowed to couple two of these over 7m long trailers. A real challenge as a captain of the road.
The trailer is supplied as a kit, unpainted. The frame and the body are made of milled polystyrene plates. The flatbed has injection-molded plastic drop sides and is covered with a real wood floor. The steel axles with Trilex double rims are suspended in the frame with leaf springs. The drawbar is made of reinforced plastic and is held at hitch height by a tension spring. The towing hitch for the motor car is included in the kit. The 1-chamber tail lights with bracket and license plate holder complete the picture.
A lighting set is optionally available for the 2-axle trailer (item no. 251004).
Technical details:
Total length approx. 460mm, length flatbed approx. 345mm, width approx. 160mm, total height approx. 125mm, weight approx. 950g.
Scope of delivery:
- Milling plates made of polystyrene for frame, bogie and flatbed
- Drop sides made of injection molded parts
- Steel axles with leaf spring suspension
- Trilex - double rims with Fulda Coloss tires
- Bracket with spare tire
- Platform with real wooden floor
- Tail lights with license plate holder
- Towing eye and drawbar made of reinforced plastic
- Decal sheet and detailed building instructions
Caution. Not suitable for children under 14 years.
item code: 251003
Drive set for the Büssing 8000 S 13
Drive set for the Büssing 8000 S 13, consisting of a 7.2 volt underfloor motor with planetary gearbox from the company Servonaut, the motor is pre-disturbed , has an idle speed of 470 rpm, the rated speed is 390 rpm, rated torque: 34.6 Ncm, the matching motor holder made of aluminum and the cardan shaft made of stainless steel with appropriate length compensation, mounting hardware and installation instructions. Contents: 1 gear motor, 1 motor holder, 1 cardan shaft, installation instructions
Caution. Not suitable for children under 14 years.
item code: 251001
Büssing 8000 S 13
Büssing 8000 S 13 as a new edition in scale 1:16
In addition to many different trucks, the Büssing 8000 S 13 was one of the most famous and also most impressive trucks of its time in the 1950s. A typical feature for this truck era were the long engine hoods, far too little horsepower and the harsh sound of the four-stroke diesel engines. The 6-cylinder engine produced only 180 hp, with the "S" standing for standing engine and the "13" for the total displacement of 13 liters.
More than 20 years ago we produced this model and distributed it through the company Conrad Electronic. After a few years we were forced to discontinue the model. So the Büssing disappeared from the market again, but the demand for the model was unbroken. Therefore we decided to resurrect it in our anniversary year. New injection molds were made for the body and add-on parts. The platform was reinforced and got a real wood floor. The interior was revised and completed with pedals, gear stick and hand brake lever.
Optionally, the headlights can be retrofitted with a lighting kit (item no. 251002). The drive set (item no. 251001) includes an underfloor motor from Servonaut, which transmits power to the rear axle via a stainless steel cardan shaft with length compensation. This gives the model enough power and the appropriate sensitivity for maneuvering with the matching 2-axle trailer (item no. 251003). This can also be optionally retrofitted with a lighting set (item no. 251004). Until the beginning of the 50's it was even allowed to couple two of these trailers. A real challenge as a captain of the road.
Technical details:
Length approx. 570mm, width approx. 160mm, height approx. 165mm, weight approx. 1,600g.
The kit is supplied unpainted.
Scope of delivery:
- Frame made of aluminum with all drill - and threaded holes
- Ball bearing rear axle made of reinforced plastic with metal differential
- Front axle made of reinforced plastic
- Ball bearing Trilex - rims in front, in the rear Trilex - double rims
- original Fulda Coloss tires plus spare tires
- Leaf spring set front and rear made of spring steel
- driver's cab consists of several plastic parts (ABS)
- flatbed made of polystyrene with drop sides made of injection molded parts and real wooden floor
- Interior, tank, air tank, splash flaps, hardware parts, exhaust etc.
- Decal sheet and detailed building instructions
Caution. Not suitable for children under 14 years.
item code: 251000
Rear axle for classic trucks
Rear axle for classic trucks, scale 1/16, reduction 3:1, bevel gears and spur differential made of hardened steel, 6 ball bearings, reinforced axle housing made of plastic, input and output shafts 5mm Ø, track width 150mm (with our Trilex - double rims item no. 220995), mounting width of the leaf springs 58mm, suitable for a frame width of 50mm, kit with detailed assembly instructions.
Attention! Not suitable for children under 14 years.
item code: 220993
Road tire Fulda Coloss
Aluminum stanchion
Aluminum stanchion, scale 1/14, made of aluminum and steel, for retrofitting and expanding, suitable for the 3-axle stanchion trailer III item code: 907629 and for the 2-axle stake trailer Riedler item code: 907622, stanchion holder can be loosened using two grub screws and repositioned or removed as required, detailed assembly instructions and fastening material, content: 1 stanchion
item code: 907652
Caution! Not suitable for children under the age of 14.
Conversion kit building material trailer
Conversion kit building material trailer, scale 1/14, suitable for flatbed trailer III item code: 907650
Technical details:
- CNC milled aluminum side walls with detailed surface engravings
- Hinge made of 1mm sheet steel
- The side walls are locked by neodymium magnets
- All 9 side walls are functional 4 hinges per board wall
- Center posts can be removed for better loading
- detailed assembly instructions + decal sheet
Weight: approx. 2,500g
Item code: 907649
Caution! Not suitable for children under the age of 14.
Flatbed trailer III made of steel
Flatbed trailer III, scale 1/14 Technical details:
- Torsion-resistant steel frame in sandwich construction
- Frame made of 3 and 1 mm sheet steel, laser cut and CNC bent
- Solid aluminum front wall
- Detailed trailer axles with dummy air springs, optionally with a +8mm lift
- Solid steel underride protection (left/right)
- Steel spare wheel holder with spare wheel
- Chrome rims with ball bearings and wide road tires
- 7-chamber taillights and license plate
- holder included 16 lashing eyes
- Real wood floor application
- 8mm aluminum bumper
- detailed assembly instructions + decal sheet
Dimensions: LxWxH: 981 x 195 x 210mm, weight: 4,400g
Item No. 907650
Caution! Not suitable for children under the age of 14.
